Alpha Wire 2213C 22/3P Twist Pair Shielded Control/Instrumentation Cable /25ft
USD 74.99 USD
Specifications
| MPN | 2213C |
| Item Length | 25 ft |
| Sheath Color | Slate (gray) |
| Brand | Alpha Wire |
| Wire Style | Stranded |
| Voltage | 300V |
| Model | 2213C |
| Per Item Length Quantity | 25 Foot |
| Conductor Material | Stranded Tinned Copper |
| Jacket Color | Slate (gray) |
| Application | Industrial |
| Country Of Origin | Mexico |
It consists of x3 twisted pairs (each pair twisted at min 8.0 twists/ft) of 22awg color-coded PVC (PolyVinyl Chloride) insulated stranded (7x30 stranding) tinned copper conductors, with all 3 pairs then cabled/twisted together at min 4.8 twists/ft, then covered with a foil shield (100% coverage aluminum foil/mylar tape backing with min 25% overlap and foil side facing out), with 22awg stranded (7x30 stranding) tinned copper drain wire, all wrapped in a slate (gray) PVC jacket.
