Fellows Series 7 High Speed Gear Shapers Operators Manual #684
Specifications
| Return Shipping Will Be Paid By | Buyer |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Refund Will Be Given As | Money Back |
| Country/Region Of Manufacture | United States |
| Item Type | Manual |
| MPN | Does Not Apply |
| Subject | Metal Cutting |
| Brand | Fellows |
Fellows Series 7 Gear Shaper Operator Manual Type of Manual: Operator For Models: Series 7: 70, 71, 72, 75, 77, 710, 712, 715, 720, 725, 7120 Description: This manual covers the Fellows Series 7 Gear Shaper. It covers Principles of Operation, The manual has about 56 pages. To view the Table of Contents, to inspect the quality of the manual, and to view select pages, please click on the gallery images above. Includes sections on:Principles of OperationSpecificationsOperating The ShaperSelecting Change GearsSetting The StrokeSetting The CutterStarting the MachineSetting for RecuttingCutting Internal GearsCutting Helical GearsTables and FormulasGear Tooth Proportions TablesNumber of Pages: Approx. 56 Publication Date: 1934 Publication No.: N/A Added Notes: Due to others making copies of these for resale, I have added a light watermark to select pages to discourage this practice. About this manual: This is a high quality reproduction manual which has been scanned with a high resolution scanner. Each page is then digitally edited in Photoshop to remove grease marks, fingerprints, writing, and other imperfections that the original manual may have had. It is then printed on 24 lb heavy paper and 65 lb cardstock for the covers with a 600 DPI LaserJet printer. The result is a clean and durable manual which many times is better than the original and should last many years in your shop. Ships USPS First Class Free unless otherwise stated or Upgrade to Priority Mail for faster delivery. Sales Tax Charged for Kansas Sales See my for more manuals.
