GV2ME16 9-14A TeSys GV2 Manual Starters and Protectors SCHNEIDER NEW SEALED BOX
Specifications
| Return Shipping Will Be Paid By | Buyer |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Refund Will Be Given As | Money Back |
| Number Of Gangs | N/A |
| Number Of Outlets | N/A |
| California Prop 65 Warning | N/A |
| MPN | GV2ME16 |
| Maximum Amperage | 9-14 A |
| Number Of Spaces | 2-5 |
| Voltage | 690VAC |
| Bundle Description | N/A |
| Suitable For | Exterior |
| Electrical Connection | Screw Terminal |
| Country/Region Of Manufacture | France |
| Control Style | Switch |
| Material | ABS/Plastic |
| Plug Type | N/A |
| Model | GV2ME16 |
| Orientation | Horizontal/Vertical |
| Application | Electrical Wiring |
| Current Rating | 14 A |
| Current Type | AC/DC |
| Operation Method | On/Off |
| Timer Control | None |
| Brand | Schneider Electric |
| Color | Black |
| Room | Any Room |
| Mounting Style | DIN Rail |
| Number Of Throws | N/A |
| Smart Home Protocol | N/A |
| Operating Temperature | 60 °C (140 °F) |
| Type | Manual Starter |
MainrangeTeSysproduct nameTeSys GV2device short nameGV2MEproduct or component typeCircuit breakerdevice applicationMotortrip unit technologyThermal-magneticComplementarypoles description3Pnetwork typeACutilisation categoryAC-3 conforming to IEC 60947-4-1Category A conforming to IEC 60947-2network frequency50/60 Hz conforming to IEC 60947-4-1fixing modeClipped on 35 mm symmetrical DIN railScrewed on panel (with adaptor plate)operating positionAny positionmotor power kW11 kW at 690 V AC 50/60 Hz9 kW at 690 V AC 50/60 Hz7.5 kW at 500 V AC 50/60 Hz5.5 kW at 400/415 V AC 50/60 Hzbreaking capacity3 kA Icu at 690 V AC 50/60 Hz conforming to IEC 60947-215 kA Icu at 400/415 V AC 50/60 Hz conforming to IEC 60947-28 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-26 kA Icu at 500 V AC 50/60 Hz conforming to IEC 60947-2100 kA Icu at 230/240 V AC 50/60 Hz conforming to IEC 60947-2[Ics] rated service short-circuit breaking capacity100 % at 230/240 V AC 50/60 Hz conforming to IEC 60947-250 % at 400/415 V AC 50/60 Hz conforming to IEC 60947-250 %at 440 V AC 50/60 Hz conforming to IEC 60947-275 % at 500 V AC 50/60 Hz conforming to IEC 60947-275 %at 690 V AC 50/60 Hz conforming to IEC 60947-2control typePush-button[In] rated current14 Athermal protection adjustment range9...14 Amagnetic tripping current170 ASystem Voltage690 V AC 50/60 Hz conforming to IEC 60947-2[Ui] rated insulation voltage690 V AC 50/60 Hz conforming to IEC 60947-2[Ith] conventional free air thermal current14 A conforming to IEC 60947-4-1[Uimp] rated impulse withstand voltage6 kV conforming to IEC 60947-2power dissipation per pole2.5 Wmechanical durability100000 cycleselectrical durability100000 cycles AC-3 at 440 Voperating rate25 cyc/hrated dutyContinuous conforming to IEC 60947-4-1connections - terminalsScrew clamp terminals 2 cable(s) 1...6 mm² solidScrew clamp terminals 2 cable(s) 1.5...6 mm² flexible without cable endScrew clamp terminals 2 cable(s) 1...4 mm² flexible with cable endtightening torque1.7 N.m on screw clamp terminalssuitability for isolationYes conforming to IEC 60947-1phase failure sensitivityYes conforming to IEC 60947-4-1height3.5 in (89 mm)width1.77 in (45 mm)depth3.08 in (78.2 mm)product weight0.57 lb(US) (0.26 kg)EnvironmentstandardsEN 60204IEC 60947-1IEC 60947-2IEC 60947-4-1NF C 63-120NF C 63-650NF C 79-130UL 508VDE 0113VDE 0660CSA C22.2
