MIDI Shield Musical Breakout Board Instrument Digital Interface Adapter Plate
USD 5.34 USD
Specifications
| Brand | Unbranded/Generic |
| MPN | MIDI Shield |
MIDI adapter plate provides MIDI - IN and MIDI - OUT connection, and MIDI THRU port. MIDI - port is light IN isolation, to prevent the ground loop. MIDI adapter plate can be installed directly like a shield at the top of the Arduino board: connect MIDI - IN/THRU to for Arduino hardware RX pin, connect MIDI - OUT to TX.
