Schneider Electric VLS3P125R2 3-Pole 125A 600VAC Load Break Switch
USD 212.56 USD
Specifications
| Motor Rating 3PH 240V | 30 HP |
| Motor Rating 3PH 480V | 60 HP |
| General Use Rating (UL) | 100A at 600VAC |
| Motor Rating 1PH 240V | 10 HP |
| AC22A Rating ≤415V | 125A |
| MPN | VLS3P125R2 |
| Standard | IEC/EN 60947-3 |
| Wire Range | 12–1 AWG stranded |
| Wire Type | Copper only, 60°C rated |
| Unit Type | Unit |
| AC22A Rating 690V | 125A |
| Insulation Voltage (Ui) | 1000V |
| Motor Rating 3PH 600V | 60 HP |
| AC23A Rating 690V | 47A |
| Input Terminals | 1L1, 3L2, 5L3 |
| AC23A Rating ≤415V | 125A |
| Motor Rating 1PH 120V | 7.5 HP |
| Terminal Tightening Torque | 45–54 lb·in |
| Actuator Type | Direct rotary handle |
| Brand | Schneider Electric |
| AC22A Rating 500V | 125A |
| Output Terminals | 2T1, 4T2, 6T3 |
| Type | Load Break Switch |
| AC23A Rating 500V | 100A |
| Conventional Thermal Current (Ith) | 125A |
| Model | Load Break Switch |
| Impulse Withstand Voltage (Uimp) | 8kV |
| Frequency | 50/60Hz |
| Country Of Origin | Italy |
The Schneider Electric VLS3P125R2 is a new, 3-pole direct-actuator load break switch (isolator) from the Vario product line, manufactured in Italy and carrying catalog number 115650. Manufacturer Part Number VLS3P125R2.
