STEPPERONLINE Nema 23 Stepper Motor Bipolar 1.8deg Φ8mm 3Nm 5A 57x100mm 4 Wires
USD 28.99 USD
Specifications
| Brand | StepperOnline |
| Full Step Angle | 1.8° (200 Steps) |
| Shaft Diameter | Φ8mm |
| MPN | 23HS39-5004S |
| Holding Torque | 3.00Nm(424.83oz.in) |
| Rated Current Per Phase | 5.0A |
| Resistance Per Phase | 0.6ohms±10% |
| Country/Region Of Manufacture | China |
| UPC | 742803041537 |
| EAN | 0742803041537 |
| Inductance | 2.8mH±20%(1KHz) |
Motor Type: Bipolar Stepper. The NEMA 23 stepper motor has a rated current of 5.0A and a holding torque of 3.0Nm(424.83oz.in). Step Angle: 1.8deg. Inductance: 2.8mH±20%(1KHz). Phase Resistance: 0.6ohms±10%.
